Global Truss DT46-200 6.56Ft (2m) DT46 Square Truss Segment

Product Description

The Global Truss DT46-200 is a 6.56 ft (2 m) straight segment designed for the professional DT46 Square Truss system. Featuring a 400 mm (15.75 in) overall square profile, 50 mm (2 in) outer-diameter tubing, and 25.4 mm (1 in) diagonal bracing, this six-chord truss segment provides a substantial structural component for professional stage, lighting, event, exhibition, and production applications.

The DT46-200 is part of the Global Truss DT46 6-chord box truss range and is identified by manufacturer SKU DT460027. Its 2 m length makes it a practical straight section for building larger modular truss structures while maintaining the DT46 system's consistent profile and connection geometry.

Key Features of Global Truss DT46-200

• Global Truss DT46-200 straight square truss segment
• 6.56 ft / 2.0 m overall length
• 400 mm / 15.75 in overall square profile
• 50 mm / 2 in outer-diameter tubing
• 25.4 mm / 1 in diagonal bracing
• 3 mm wall thickness
• Six-chord DT46 square truss design
• 56 lb unit weight
• Designed for professional stage, event, lighting, and production applications
• Part of the Global Truss DT46 modular truss system

Technical Specifications

• Brand: Global Truss
• Model: DT46-200
• SKU: DT460027
• Truss Series: DT46
• Truss Type: 6-Chord Square / Box Truss
• Overall Length: 6.56 ft / 2.0 m
• Overall Width: 15.75 in / 400 mm
• Outer Tubing Diameter: 2 in / 50 mm
• Diagonal Bracing: 1 in / 25.4 mm
• Wall Thickness: 0.12 in / 3 mm
• Unit Weight: 56 lb

DT46-200 for Stage, Lighting & Event Structures

The 2 m length of the DT46-200 makes it useful for creating straight runs within larger truss structures. It can be incorporated into professional event and production environments where compatible DT46 components are required for a modular truss configuration.

Typical applications include stage lighting structures, concert and entertainment production, exhibition displays, trade show structures, event installations, and other professional truss applications. Always verify the complete structure, support configuration, equipment loads, applicable load tables, and local safety requirements before installation.

Build Larger Truss Structures with DT46 Components

The DT46-200 can be used as a straight section within a compatible DT46 system. Additional DT46 straight segments and compatible junction components can be selected according to the required structure and configuration.

Global Truss provides dedicated DT46 load tables for structural reference. Load capacities depend on span length, support configuration, loading conditions, and installation method, so the manufacturer's load documentation should be reviewed before using the truss for a specific application.

Why Choose the Global Truss DT46-200?

The Global Truss DT46-200 combines a 2 m length with the substantial 400 mm DT46 profile, making it a useful straight segment for professional truss structures. Its 50 mm main tubing and 25.4 mm diagonal bracing provide the dimensional configuration associated with the DT46 six-chord system.

For production companies, event professionals, lighting designers, exhibition builders, and staging professionals, the DT46-200 provides a standardized straight section for compatible DT46 configurations.

Buy Global Truss DT46-200 from USATRUSS

Shop the Global Truss DT46-200 6.56 ft (2 m) DT46 Square Truss Segment from USATRUSS for professional stage, lighting, event, exhibition, and production applications. USATRUSS offers Global Truss products and professional truss solutions for customers across the United States.

Need help selecting DT46 truss segments or compatible components for your project? Contact USATRUSS or call 1-800-856-8397 for assistance.

Frequently Asked Questions About Global Truss DT46-200

What is the Global Truss DT46-200?

The Global Truss DT46-200 is a 6.56 ft (2 m) straight segment from the DT46 six-chord square truss system. It features a 400 mm square profile and is designed for professional truss structures.

What are the dimensions of the DT46-200?

The DT46-200 has an overall length of 6.56 ft (2 m) and an overall square profile of 400 mm (15.75 in). It uses 50 mm (2 in) outer-diameter tubing with 25.4 mm (1 in) diagonal bracing.

How much does the Global Truss DT46-200 weigh?

The DT46-200 has a listed unit weight of 56 lb.

What type of truss is the DT46-200?

The DT46-200 is a six-chord square or box truss segment from Global Truss's DT46 series.

Where can I buy the Global Truss DT46-200?

You can shop the Global Truss DT46-200 from USATRUSS. For assistance with DT46 components, configurations, or project requirements, Contact USATRUSS or call 1-800-856-8397.
